2-Port 4K DisplayPort Çoklayıcıbrn2-Port 4K DisplayPort Splitter

It allows the image of the source device broadcasting DisplayPort to be viewed on 2 different DisplayPort displays at the same time. DisplayPort 1.2a (3D, Deep Color, 4K); Supports HDCP 1.3. Supports resolutions of 4096 x 2160 / 3840 x 2160 @ 60 Hz. DisplayPort allows the image of the source device broadcasting to be watched in 4K resolution from 2 different DisplayPort displays at the same time. It can work in MST / Extend Mode and SST / Split Mode*
MST/Extend Mode:
It allows the image of the source device broadcasting DisplayPort to be spread across two screens at 4K resolution.
SST/ Split Mode:

​DisplayPort allows the image of the source device broadcasting to be viewed at 4K resolution on 2 different DisplayPort displays at the same time.

Linkrate: Supports HBR2 (High Bit Rate 2).
Note:
* ATEN-VS192 EDID Mod feature works in SST Mode. It automatically recognizes the resolution of the monitor connected to port 1.

Display OutputInterfaces2 x DisplayPort Female (Black Colour)Display InputInterfaces1 x DisplayPort Female (Black Colour)DisplayCompatibilityDP 1.2a; HDCP 1.3Max. Resolution4096 x 2160 / 3840 x 2160 @ 60HzMax. Data Rate21.6 Gbps (5.4 Gbps per lane)PowerConnectors1 x DC JackConsumption5 VDC, 1.185WEnvironmental FeaturesTemperature of Working Environment0-40 °CTemperature of Storage Area-20 - 60 °CHumidity Rate0 - 80% RH, Non-CondensingPhysical FeaturesChassisMetalWeight0.30 kg ( 0.66lb )Dimensions (W x L x H)12.50 x 8.00 x 2.50 cm
(4.92 x 3.15 x 0.98 in.)

Packaging Content

1 x ATEN-VS192 2-Port 4K DisplayPort Multiplexer1 x Power Adapter1 x User Manual
